2026 Utility Trailer 4000AE - NT-2863-COL
Get in Touch
Description
2026 Utility Trailer 4000AE
The 4000AE comes standard with a 47,000 lb coil haul package, yet weighs less than some all-aluminum trailers. It optimizes weight without a sacrifice to strength. Utility 4000AE can also be custom built with a variety of options to meet your operational requirements.
Dealer Notes
2026 Utility 48' Combo Flatbed
- 48' x 102"
- 3" aluminum I-beam crossmembers on 12" centers (full length)
- Hendrickson air ride/slide suspension w/49" axle spacing
- Hendrickson solenoid operated dump valve (Not connected, wire is loose at nosebox)
- Yokohama 22.5 low profile tires on Steel disc wheels
- J-Track with ten J-hooks and storage
- Jost landing gear
- Conmet wheel ends with eight year warranty
- Drum brakes
We have many great finance options available. Please contact us for more details!
Info
Industry
Trailer
Make
Utility Trailer
Model
4000AE
Trim
Base
Year
2026
Stock Number
NT-2863-COL
Category
Flatbed Trailer
Subcategory
Flatbed Trailer
Condition
New
Location
Columbus
Vin
1UYFS2484T5529203
Axles
2
Length
48'
Width
102"
Suspension
Air Ride
Specifications
GVWR
73,000 lbs
Max Load
Payload: 80,000 lbs evenly distributed mainbeam
Length
Overall: 48 ft 0 in
Height
Overall: 583/16 in on 47" height 5th wheel
Width
Overall: 102 in
Notes
Deck Style: Straight
Crossmembers
3 in aluminum I-beam crossmembers on 16 in center line full length; (9) 4 in tapered aluminum crossbars on 8 in center lines
Floor
Type: 1 1/8 in extruded aluminum flat top floor with hardwood nail strips at each side rails (2)
Electrical
Electrical receptacle: 7-way without circuit breakers | Main harness: Utility moisture-resistant 6-wire harness with internal ground and 7-way plug
Lights
Clearance lights quantity: 1 top front corner diagonal (each side), 1 center of trailer (each side), 1 rear corner gusset (each side), 3 at rear | Lower clearance lights: 2 1/2 in round Grote® Ultra Seal 10 type | Side mounted directional light: Grote® Ultra Seal 60 integral with center clearance light | ABS warning light: Grote® Micronova® LED PC-rated | Stop, tail, turn lights: Grote® 4" LED (10-diode) lights, 2 per side with black snap-in flange
Finish
Frame: Utility black enamel with primer undercoat on all steel show surfaces; aluminum parts receive a natural finish
Wheels
22.5 in × 8.25 in standard width wheels Factory choice steel 10 hub piloted wheels
Tires
Michelin® 275/80R 22.5 XTE 14 ply, load range G
